Period 1: Computational Thinking — Algorithms & Flowcharts

What Is an Algorithm?

An algorithm is a finite, step-by-step set of unambiguous instructions designed to solve a specific problem or perform a computation. Unlike a vague set of suggestions, a well-formed algorithm has five key traits:

Characteristic	Meaning	Classroom Example
Input	Zero or more externally supplied values	A student's two quiz scores
Output	At least one result is produced	A calculated average
Definiteness	Each step is precise and unambiguous	"Add the numbers," not "Do some math"
Finiteness	The process terminates after a limited number of steps	The calculation ends; it does not loop forever
Effectiveness	Operations are basic enough to be carried out exactly and in finite time	Addition, comparison, or movement

Key Insight: A recipe is the classic analogy, but in computing, an algorithm must be so precise that a machine—with no intuition—could execute it successfully.

Example Algorithm A — Making Tea (Sequential)

1. Boil water in a kettle until it reaches 100 °C.
2. Place one teabag into a cup.
3. Pour 250 ml of hot water into the cup.
4. Steep for exactly 3 minutes.
5. Remove the teabag and discard.
6. If milk or sugar is desired, add to taste.
7. Serve.

Example Algorithm B — Calculating a Class Average (Mathematical)

1. Input: Receive five test scores.
2. Process: Sum the five scores.
3. Process: Divide the sum by 5.
4. Output: Display the average.
5. Decision: If average ≥ 60, output "Pass"; else, output "Retake."
6. End.

Bridging to Code: Pseudocode

Before drawing, students can write pseudocode—a plain-language outline that mirrors programming logic without formal syntax. It serves as the bridge between human thought and machine instructions.

START
  INPUT temperature
  IF temperature < 20°C THEN
    OUTPUT "Wear a coat"
  ELSE
    OUTPUT "Wear sunglasses"
  END IF
END

Visualizing Logic: Flowcharts

A flowchart is a graphical representation of an algorithm. It forces students to externalize decision points and loops that are often hidden in prose.

Standard Flowchart Symbols

Symbol	Name	Purpose
Oval	Terminal	Start / End
Parallelogram	Input / Output	Receiving data or displaying results
Rectangle	Process	Calculations, assignments, or actions
Diamond	Decision	Yes / No or True / False branches
Circle	Connector	Links flowcharts across multiple pages
Arrows	Flow Lines	Indicate direction of control

Example Flowchart: "What Should I Wear?"

      [Start]
         |
         V
[Input: Is the temp < 20°C?]  <---- (Diamond)
         |            |
      Yes |            | No
         V            V
[Output: Wear]    [Output: Wear]
[a coat]          [sunglasses]
         |            |
         +---->[End]<-----+

Common Pitfalls to Address

• Ambiguity: "Get ready" is too vague. Break it into "Put on shoes," "Grab backpack," etc.
• Missing terminals: Every flowchart must have one Start and at least one End.
• Dead ends: Ensure every decision diamond has both Yes and No arrows leading somewhere.

---

Period 2: Block-Based Programming — Introduction to Scratch 3.0

What Is Scratch?

Scratch (scratch.mit.edu) is a visual, block-based programming language developed by the MIT Media Lab. Instead of typing syntax-sensitive text, students snap together interlocking puzzle pieces that represent commands. This lowers the barrier to entry and eliminates syntax errors, allowing learners to focus on logic and structure.

Key Insight: Block-based coding is not "training wheels"—it is a legitimate paradigm that teaches the same computational thinking concepts (sequencing, loops, conditionals, events) used in professional text-based languages.

The Scratch 3.0 Interface

Component	Location / Icon	Function
Stage	Top-right area	The 480 × 360 pixel "theater" where sprites move, speak, and interact.
Sprite	Bottom-right pane	Any character or object that performs actions. Projects can contain many sprites.
Sprite Info	Above the sprite list	Name, x/y position, direction, size, visibility, and draggable state.
Blocks Palette	Left column	Color-coded categories: Motion (blue), Looks (purple), Sound (pink), Events (yellow), Control (orange), Sensing (light blue), Operators (green), Variables (red), and My Blocks (pink).
Scripts Area	Center workspace	The canvas where blocks are assembled into programs.
Tabs	Top of Scripts Area	Code (programming), Costumes (visual editor for sprite appearances), Sounds (audio recorder/editor).
Backdrops	Bottom-right, next to Sprites	Background images for the Stage. Clicking the Stage reveals its own Backdrops tab.
Green Flag	Above the Stage	The universal "run" button; most projects begin with an Events block tied to this flag.
Backpack (online)	Bottom of screen	Stores sprites, scripts, or sounds to carry between projects.

Core Concept: Events & Sequencing

Every program needs a trigger. In Scratch, Events blocks (yellow) listen for an action and then run the attached script.

Common event triggers include:

• when [green flag] clicked — Standard program start.
• when [space] key pressed — Keyboard input.
• when this sprite clicked — Mouse/touch interaction.
• when I receive [message] — Inter-sprite communication (broadcasting).

Once triggered, blocks execute in top-to-bottom sequence—exactly like the steps in an algorithm.

Your First Script: "Hello World" Expanded

This activity moves beyond a single block to demonstrate sequencing.

1. From the Events palette, drag when green flag clicked into the Scripts Area.
2. From the Looks palette, snap say Hello! for 2 seconds beneath the Events block.
3. From the Motion palette, snap move 10 steps beneath the Looks block.
4. From the Sound palette, snap start sound Meow (or any available sound) at the bottom.
5. Click the Green Flag above the Stage.

Expected Behavior: The sprite says "Hello!", glides forward, and plays a sound—one after another, not simultaneously.

Computational Thinking Tie-In

Remind students that the script they just built is an algorithm. If they were to draw it as a flowchart, it would look like:

[Start: Green Flag Clicked]
         |
         V
[Process: Say "Hello!" for 2s]
         |
         V
[Process: Move 10 steps]
         |
         V
[Process: Play sound]
         |
         V
       [End]

Debugging & Best Practices

• Test often: Run the script after adding every two or three blocks. If it breaks, you know exactly where the new problem is.
• Readability: Right-click the Scripts Area and select "Clean up Blocks" to align everything neatly.
• Naming: Click the sprite's name in the Sprite Info pane to rename it (e.g., "Cat" → "Player") before scripts reference it.
• Saving: If using the online editor, remind students to sign in to save to the cloud; otherwise, use File > Save to your computer.

Assessment & Exit Ticket

Before logging off, students answer in a digital exit ticket or on paper:

1. What is the difference between a sprite and a backdrop?
2. Which block category contains the trigger that starts your program?
3. Transfer Question: How is the order of blocks in your Scratch script similar to the steps in the tea flowchart from Period 1?

---

Materials & Preparation

• Period 1: Printed flowchart symbol reference sheets, whiteboard markers, or access to a simple drawing tool.
• Period 2: Devices with internet access and scratch.mit.edu unblocked; headphones recommended for sound exploration.
